KIT TELAIO
- TELAIO: Full Integrated Battery, Alloy Triple Butted, 12x148 Boost, Horst Link 4, Wheel travel: 150 mm, Tire clearance 29 x 2.6
- FORCELLA: Rock Shox 35 Silver R 29" Boost 15x110mm 160mm E-MTB Tapered Steerer
- AMMORTIZZATORE: Rock Shox Deluxe Select R 205x65 Debonair Tune Trunnion
- SERIE STERZO: FSA Orbit 1,5 E ZS 1-1/8” 1,5”
COMPONENTI ELETTRONICI
- MOTORE: Shimano EP8 250W
- BATTERIA: Integrated LI-ION Battery, 630 Wh
- DISPLAY: Shimano EP8
TRASMISSIONE
- DERAGLIATORE POSTERIORE: Sram SX Eagle 12s
- MANIGLIE CAMBIO: Sram SX Eagle 12s
- GUARNITURA: Sram Chainring 36T
- PIGNONI: Sram SX Eagle 12s 11-50t
FRENI
- FRENI: Shimano MT420 hydraulic disc 4-Piston, 203mm
RUOTE
- PNEUMATICI: Front: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection
- MOZZO: Boost System 15x110 12x148, E-Bike+
- CERCHIONI: 29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready
COMPONENTI
- MANUBRIO: Alloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6º
- STELO: 3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º
- REGGISELLA: Megamo 30,9mm telescopic seat post, remote adjustment
- SELLA: Sellie Italia Model X Superflow
